Riedel Bolero User Manual

34
Bolero User Manual A20
2.4.14.2 Charging in the Charger
· Plug the Beltpack or just the battery itself in an
empty position in the charger.
The radio is switched off when the Beltpack is plugged into the Charger.
· The charging procedure will start automatically.
· The Beltpack's display and the corresponding
Slot LED indicate the current charging state.
For further information refer chapter Bolero Charger.

Riedel Bolero Specifications

General

Encryption	AES-256
Type	Wireless Intercom System
Frequency Bands	1.9 GHz
Charging Time	3 hours
Protection Class	IP54
Operating Temperature	-10°C to +50°C
Connectivity	AES67
Beltpack Capacity per Antenna	10 beltpacks
Network	Ethernet
Headset Connector	XLR 4-pin
Power	12 V DC
Channel Bandwidth	1.728 MHz
Modulation	GFSK
Data Rate	1152 kbps
Power Supply	PoE (Power over Ethernet)
Power Consumption	15 watts
Dimensions (Base Station)	483 x 44 x 280 mm
Weight (Base Station)	3.5 kg
Battery Life	Up to 17 hours
Operating Range	300m (line of sight)
