Bolero User Manual A20
· When the Beltpack is fully charged, the display
shows the following content.
· Remove the Beltpack or battery out of the
charger.
4.4 Technical Specifications
Charger Product Code
BL-CHG-1005-R
No of Beltpack slots
5
Beltpack Charge Time
up to 180 minutes
Charge status LEDs
1 per charge slot
Beltpack Display
% charged, time to full, temperature, battery health
USB Type-A / USB Type-C
Connection
· For firmware update
· For charging a Beltpack, a phone, etc. via cable
· Max. 1.8 A (each port)
Power Socket
1x IEC
Power Supply
100 ... 230 VAC / 50 ... 60 Hz
Mounting
Stand-alone table mount, 2x wall mounts or 19” rack via optional
accessory kit "BL-RMK-1002-01" (1430045)
Dimensions
Width
380 mm / 15"
Height
95 mm / 3.8"
Depth
135 mm / 5.3"
Weight
1140 g
Operating Environment
Ambient
Temperature
0° … +45°C
Humidity
20 % ... 90 % rel. (non-condensing)
Storage Temperature
-20° ... +70°C
