Bolero User Manual A20
2.4.14.3 Replacing the Battery
The Beltpack battery can be replaced by following these steps:
· Pull the battery release button upwards...
· and push the battery at the belt clip to the bottom side of the Beltpack.
· Lift the battery upwards.
· Insert the battery in the opposite order.
Figure 29: Pull release button
Figure 30: Push battery
Figure 31: Lift battery
2.4.14.4 Removing the Belt Clip
The belt clip can be removed by following these steps:
· Pull the lock clip upwards...
· and push the belt clip to the top side of the battery.
· Insert the belt clip in the opposite order.
Figure 32: Pull lock clip
Figure 33: Push belt clip
