39
5.4. RF signal generator
The output signal of RigExpert AA-600, AA-1000 and AA-1400 has rectangular
waveform and level of about -10 dBm (at the 50 Ohm load). Therefore these analyzers
can be used as sources of RF signal for various purposes.
For frequencies up to 200 MHz, first harmonic of output signal can be used. Above 200
MHz, tune your receivers to odd higher harmonics.
Enter the SWR mode or the Show all mode, and press the
(ok) key to start the RF
output.
If needed, use the frequency correction option in th
e Settings menu (see page 24).
6. Troubleshooting
Before asking for a tech support, please make sure t
o run RF bridge, detector and band-
pass filter tests (see pages 25-27 for details). You may also visit our website,
www.rigexpert.com , select your analyzer model from the list and then click
Troubleshooting.
