User’s Guide for DG1022
5-4
DC Offset
CH1
CH2
Range (DC)
5V (50)
10 V (High Z)
1.5V (50)
3 V (High Z)
Accuracy
± (2% of the |Offset
Setting|+ 2mV)
± (2% of the |Offset
Setting|+ 2mV)
Waveform Output
CH1
CH2
Impedance
50  typical
50  typical
Protection
[2]
Short-circuit protected,
overload relay
automatically disables
main output
Short-circuit protected
AM (CH1)
Carrier Waveforms
Sine, Square, Ramp, Arb (Except DC)
Source
Internal/ External
Modulating Waveforms
Sine, Square, UpRamp, DnRamp,Triangle, Noise, Arb
(2mHz to 20kHz)
Depth
0% ~ 120%
FM (CH1)
Carrier Waveforms
Sine, Square, Ramp, Arb (Except DC)
Source
Internal/ External
Modulating Waveforms
Sine, Square, UpRamp, DnRamp,Triangle, Noise, Arb
(2mHz to 20kHz)
Frequency Deviation
DC~ 10 MHz
PM (CH1)
Carrier Waveforms
Sine, Square, Ramp, Arb (Except DC)
Source
Internal/ External
Modulating Waveforms
Sine, Square, UpRamp, DnRamp,Triangle, Noise, Arb
(2mHz to 20kHz)
Phase Deviation
0 to 360°
FSK (CH1)
Carrier Waveforms
Sine, Square, Ramp, Arb (Except DC)
Source
Internal/ External
