Modulating Waveforms
50% duty cycle square (2mHz to 50kHz)
Sweep (CH1)
Carrier Waveforms
Sine, Square, Ramp, Arb (Except DC)
Type
Linear or Logarithmic
Direction
Up or Down
Sweep Time
1 ms to 500 s ± 0.1%
Source
Internal/External/Manual
Burst (CH1)
Waveforms
Sine, Square, Ramp, Pulse, Noise, Arb (Except DC)
Types
Count (1 to 50,000 periods), infinite, gated
Start Phase
-180° to +180°
Internal Period
1 µs – 500s ± 1%
Gate Source
External Trigger
Trigger Source
Internal/External/Manual
Rear Panel Connector
[3]
External Modulation
± 5 VPK = 100% modulation
5k input impedance
External Trigger
TTL-compatible
Trigger Input
Input Level
TTL-compatible
Slope
Rising or falling (selectable)
Pulse Width
> 100 ns
Input Impedance
> 10 k, DC coupled
Latency
Sweep: < 500 µs (typical)
Burst: < 500 ns (typical)
Trigger Output
Level
TTL-compatible into >1k
Pulse Width
> 400ns typical
Output Impedance
50, typical
