User’s Guide for DG1022
5-6
Maximum Rate
1 MHz
Sync Output (CH1)
Level
TTL-compatible into >1k
Pulse Width
> 50ns (typical)
Output Impedance
50 (typical)
Maximum Frequency
2 MHz
Counter Specification
Function
Frequency, period, positive/negative Pulse width, Duty
cycle
Frequency range
Single channel: 100mHz ~ 200MHz
Frequency resolution
6 digits/second
Voltage range and sensitivity (not modulated signal)
Auto mode
1Hz to 200MHz
200 mVPP to 5 VPP
Manual mode
DC
DC offset range
± 1.5 VDC
100mHz~100MHz
20m VRMS to ± 5 Vac+dc
100MHz~200MHz
40m VRMS to ± 5 Vac+dc
AC
1Hz~100MHz
50m VPP to ± 5 VPP
100MHz~200MHz
100m VPP to ± 5 VPP
Pulse width
and Duty cycle
measure
1Hz to 10MHz (100mVPP ~ 10VPP)
Input adjust
Input impedance
1MΩ
Coupling mode
AC, DC
High frequency restrain
High frequency noise restrain
(HFR) on or off
sensitivity
Low, Medium, High
Trigger mode
The trigger level can adjust manually/ automatically
Trigger level range: ± 3 V (0.1% to 100％)
Resolution: 6 mV
NOTE:
[1] In atypical condition, the specification may have minor differences.
[2] In normal temperature, short circuit in less than half hour will be tolerable.
