Rigol DHO804 User Manual

This series supports selecting multiple files or folders to operate on. You can also click
or tap the icon
at the upper-right corner of the interface to select all the files and
folders under the current disk. Click or tap
to cancel the select-all operation.
Cut, Copy, or Paste a File or a Folder
• Cut a File to a Specified Folder
Select a specified file or folder. Click or tap
Cut to cut the specified file or folder.
Then select the destination folder. Then click or tap
Paste to paste the specified
file or folder to the destination folder.
• Copy a File to a Specified Folder
Select a specified file or folder. Click or tap Copy to copy the specified file or
folder. Then select the destination folder. Then click or tap
Paste to paste the
specified file or folder to the destination folder.
Delete a File or Folder
In the current folder, select the file or folder to be deleted. Click or tap
Delete, then a
prompt message "Are you sure to delete the file?" is displayed. Click or tap
OK to
delete the file. Otherwise, click or tap
Cancel to cancel the deletion operation.
Rename a File or Folder
Select a specified file or folder, then click or tap
Rename to input a new filename or
folder name with the pop-up virtual keypad. Then, the rename operation is
completed.
Store and Load
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO800 User Guide
213

Rigol DHO804 Specifications

General

Bandwidth	70 MHz
Channels	4
Waveform Capture Rate	1, 000, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	12 bits
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ ± 1%
Max Input Voltage	300 Vrms CAT I
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Runt, Window, Delay, Setup/Hold, Nth Edge, Logic
Protocol Decoding	I2C, SPI, UART, CAN, LIN, FlexRay, I2S
USB Ports	USB Host, USB Device
LAN Port	1
