Rigol DHO804 User Manual

21 System Utility Function Setting ..............................................................................214
21.1 I/O Setting .........................................................................................................................................214
21.2 Basic Settings ................................................................................................................................... 216
21.3 About this Oscilloscope ................................................................................................................218
21.4 Other Settings ..................................................................................................................................219
21.5 Auto Config .......................................................................................................................................219
21.6 SelfCal .................................................................................................................................................220
21.7 Option List .........................................................................................................................................220
21.8 Quick Action Settings ....................................................................................................................220
21.9 Self-check .......................................................................................................................................... 223
22 Remote Control ............................................................................................................224
22.1 Remote Control via USB ...............................................................................................................225
22.2 Remote Control via LAN ...............................................................................................................225
23 Troubleshooting ...........................................................................................................227
24 Appendix ........................................................................................................................228
24.1 Appendix A: Options and Accessories .................................................................................... 228
24.2 Appendix B: Warranty ................................................................................................................... 228
24.3 Appendix C: Factory Settings ..................................................................................................... 229
DHO800 User Guide
VI
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO804 Specifications

General

Bandwidth	70 MHz
Channels	4
Waveform Capture Rate	1, 000, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	12 bits
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ ± 1%
Max Input Voltage	300 Vrms CAT I
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Runt, Window, Delay, Setup/Hold, Nth Edge, Logic
Protocol Decoding	I2C, SPI, UART, CAN, LIN, FlexRay, I2S
USB Ports	USB Host, USB Device
LAN Port	1
