Rigol DHO804 User Manual

Source Selection
Click or tap the
Source drop-down button to select CH1-CH4. For details, refer to
Trigger Source . The selected trigger source is indicated in the trigger information
label at the top of the screen.
Only when you select the channel that has signal inputs as the trigger source, can you
obtain a stable trigger.
Polarity
Select the pulse polarity of Runt trigger under the
Polarity item.
• Positive
: indicates that the instrument triggers on the positive runt pulse.
• Negative
: triggers on the negative runt pulse.
Trigger Condition
Set the Runt trigger condition in the
When item.
• None: indicates not setting the trigger condition of Runt trigger.
• >: triggers when the runt pulse width is greater the Lower limit of pulse width.
Click or tap the input field of
Lower to set the minimum pulse width of Runt
trigger with the pop-up numeric keypad. You can also use the corresponding
multipurpose knob to modify the value.
• <: triggers when the runt pulse width is smaller than the upper limit of pulse
width. Click or tap the input field of
Upper to set the maximum pulse width of
Runt trigger with the pop-up numeric keypad. You can also use the
corresponding multipurpose knob to modify the value.
• < >: triggers when the runt pulse width is greater than the lower limit and
smaller than the upper limit of pulse width. Click or tap the input field of
Upper
to set the maximum pulse width of Runt trigger with the pop-up numeric
keypad. Click or tap the input field of
Lower to set the minimum pulse width of
Runt trigger with the pop-up numeric keypad. You can also use the
corresponding multipurpose knob to modify the maximum and minimum pulse
width. The lower limit of the pulse width must be smaller than the upper limit.
Trigger Mode
In
Sweep, select Auto, Normal, or Single as the trigger mode. For details, refer to
descriptions in
Trigger Mode .
Trigger Parameter Setting
You can refer to
Trigger Holdoff and Noise Rejection to set the trigger holdoff and
noise rejection under this trigger type.
Triggering the Oscilloscope
DHO800 User Guide
84
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

Rigol DHO804 Specifications

General

Bandwidth	70 MHz
Channels	4
Waveform Capture Rate	1, 000, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	12 bits
Interfaces	USB, LAN, HDMI
Input Impedance	1 MΩ ± 1%
Max Input Voltage	300 Vrms CAT I
Trigger Types	Edge, Pulse, Slope, Video, Pattern, Duration, Timeout, Runt, Window, Delay, Setup/Hold, Nth Edge, Logic
Protocol Decoding	I2C, SPI, UART, CAN, LIN, FlexRay, I2S
USB Ports	USB Host, USB Device
LAN Port	1
