Figure 2-67 Table 2-39 The Display menu (Page 2/3)
Menu
Sett
ings
Comments
Grading
On
Off
The waveform is displayed in
multiple levels of pixel intensity.
Grid
Display grids and coordinates on the
screen
.
Turn off the grids
.
Turn off the grids and coordinates.
Menu
Display
1s
2s
5s
10s
20s
Infinite
Set the time before menu
fades
away
. T
he menu will be hidden after
the set time of
last button pressing.
Figure 2-68 Table 2-40 The Display menu (Page 3/3)
Menu
Settings
Comments
GridBright
<
percentage
>
Set up grid brightness.
Screen
Normal
Inverted
Set to normal mode.
Set to invert color display mode.
Screen
persist
To show the last acquired waveform
when the acquisition is stopped.
To show the accumulated acquired
waveforms when the acquisition is
stopped.
Skin
Classical
Modern
Tradition
Succinct
To set the display screen of the
oscilloscope
