User’s Guide for DS1000B series
2-64
External Memory
Press Stor
age
ė
External
to go to the following menu.
Figure 2-76
T
able 2-47 The Memory menu
Menu
Settings
Comments
Explorer
Pa
th
Director
y
File
Switch among P
ath, Directory
and F
ile.
New File
(F
older)
T
o create new f
ile or folder
.(see
table 2-13)
Delete File
(F
older)
Delete f
ile
(F
older).
Load
Recall w
avef
orm and setup
from
USB storage device
.
File system is as follows:
Figure 2-77
File system display screen
Files
File info.
Current directory
Back to previous
folder
Path
91
93
