RIGOL
© 2008 RIGOL T
echnologies, Inc.
User’s Guide for DS1000B Seri
es
2-67
Rename
Press Stor
age
ė
Disk Mana
.
ė
Rename
to go to the fo
llowing menu.
Figure
2-81 T
able
2-50
The
Rename
menu
Menu
Settings
Comments
T
o move the input focus point
of f
ile name up and down.
T
o move the focus point to the
next location.
T
o delete chose
n letter
.
OK
Rename the f
ile
.
The Rename system screen is as f
ollows:
Figure 2-82
Rename the f
ile
94
96
