16 Specifications RIGOL
DS6000 User’s Guide 16-3
Vertical
Bandwidth (-3 dB)
(50 Ω)
DS606X: DC to 600 MHz
DS610X: DC to 1 GHz
Single-shot Bandwidth
(50 Ω)
DS606X: DC to 600 MHz
DS610X: DC to 1 GHz (each channel)
Vertical Resolution 8 bits, two channels sample at the same time
Vertical Scale 2 mV/div to 5 V/div (1 MΩ)
2 mV/div to 1 V/div (50 Ω)
Offset Range 2 mV/div to 124 mV/div: ±1.2 V (50 Ω)
126 mV/div to 1 V/div: ±12 V (50 Ω)
2 mV/div to 225 mV/div: ±2 V (1 MΩ)
230 mV/div to 5 V/div: ±40 V (1 MΩ)
Bandwidth Limit
[2]
20 MHz or 250 MHz
Low Frequency
Response
(AC Coupling -3 dB)
≤5 Hz (on BNC)
Calculated Rise Time
[2]
DS606X: 600 ps
DS610X: 400 ps
DC Gain Accuracy ±2% full scale
DC Offset Accuracy
200 mV/div to 5 V/div: ±0.1 div ± 2 mV±0.5% offset
value
1 mV/div to 195 mV/div: ±0.1 div ± 2 mV±1.5% offset
value
ESD Tolerance ±2 kV
Channel to Channel
Isolation
DC to maximum band width: >40 dB
