DS6000 User’s Guide
12-19
Track
Cursor A
CH1
Cursor B
CH2
CurA
-4*1 us
CurB
4*1 us
Storage Setting (SAVE)
Storage Type
Traces
Utility Function Setting (UTIL)
I/O Setting
Network
Configuration
Mode
DHCP, Auto IP
USB Device
Computer
Sound
Sound
OFF
Pass/Fail Test
Enable Test
OFF
Source
CH1
Operate
OFF
X Mask
0.24div
Y Mask
0.38div
Message Display
OFF
Stop On Output
OFF
Output
Fail
Waveform Recording
Mode
OFF
End Frame
3998
Operate
OFF
Play mode
Single
Interval
100 ns
Start Frame
1
Current Frame
1
End Frame
3998
System Setting
