1 Quick Start RIGOL
DS6000 User’s Guide 1-11
2. Connect the other end of T2R1000 adaptor to the analog channel input terminal
or external trigger input terminal (refer to "Front Panel Overview") of the
oscilloscope on the front panel correctly.
3. Connect the ground terminal of Tek probe to the ground terminal of the circuit.
Connect the probe tip of Tek probe to the test point of the circuit under test.
For the specified model of Tek probe, you can perform probe calibration and offset
voltage adjustment after the probe is connected according to your need. For the
details, refer to "Probe".
Connect DS6000 Oscilloscope
