DS6000 User’s Guide

6-24

All Measurement

All measurement could measure all the time and voltage parameters (totally 18) of

the current measurement source and display the results at the bottom of the screen.

Press MEAS  Display All to turn the function on or off.

 When all measurement is turned on, “One-key” measurement is also valid.

 “Clear” will not clear all the measurement results.

All Measurement

One-key

Measurement

Main Page
