RIGOL
DS6000 User’s Guide
13-15
Aux Output
Users can set the signal type output from the [Trig Out/Calibration] connector at the
rear panel.
Press UTIL  AuxOutput to select the desired output type.
1. TrigOut
After this type is selected, the oscilloscope output a signal that can reflect the
current capture rate of the oscilloscope at each trigger.
2. Quick Edge
After this type is selected, the oscilloscope can output a quick edge signal which
can be used in the self-calibration of the oscilloscope.
3. GND
After this type is selected, the oscilloscope can output a ground level.
4. PassFail
After this type is selected, the oscilloscope will output a pulse signal when failed
waveforms are detected. Connect this signal to other control systems to
conveniently view the test results.
