RIGOL
DS6000 User’s Guide
Power Status
Users can set the power status of the oscilloscope after power-on. Connect the
oscilloscope to the AC source using the power cord and turn on the power switch at
the rear panel, the oscilloscope is powered on.
Press UTIL PowerStatus to select “Default” or “Open”.
Default: after the oscilloscope is powered on, you need to press the power key
at the front panel to start up the oscilloscope.
Open: after the oscilloscope is powered on, it starts up directly. Note that at this
point, you can also press the power key at the front panel to turn off the
oscilloscope.
External Trigger Impedance
Users can set the input impedance of the [EXT TRIG] connector at the front panel.
Press UTIL Ext Trigger to select “1 MΩ” (default) or “50 Ω”.
