DS6000 User’s Guide
Cursor Measurement
Cursors are the horizontal and vertical marks that can be used to measure the X axis
values (usually Time) and Y axis values (usually Voltage) on a selected waveform.
Please connect the signal to the oscilloscope and obtain stable display before using
cursor measurement. All the “Auto Measure” parameters can be realized through
cursor measurement.
Press the front panel function menu CURS Mode, use to select the desired
cursor mode (the default is OFF) and then press the knob. The modes available
include: Manual, Track and Auto.
