RIGOL 11 Display Control

11-4 DS6000 User’s Guide

3. Infinite

In this mode, the oscilloscope displays the waveform newly acquired without

clearing the waveforms acquired formerly. The waveforms acquired formerly will

be displayed in relatively low-brightness color and the waveform newly acquired

will be displayed in normal brightness and color. Infinite persistence can be used

to measure noise and jitter and to capture incidental events.
