RIGOL
DS6000 User’s Guide
13-6
USB Device
This oscilloscope can communicate with a PC or PictBridge printer via the USB
Device interface at the rear panel. You need to set the oscilloscope to make it match
with different device types.
Press UTIL  IO Setting  USB and use to select the desired device type.
 Computer: under this type, the oscilloscope can communicate with a PC.
 PictBridge: under this type, the oscilloscope can communicate with a PictBridge
printer.
To Set the GPIB Address
When using the GPIB method to control the oscilloscope, you need to use the
USB-GPIB module (need to order separately) to extend a GPIB interface for the
oscilloscope.
To set the GPIB address, press UTIL  IO Setting  GPIB and use to input
the desired address. The default is 0 and the range available is from 0 to 30.
