RIGOL
DS6000 User’s Guide
When X-Y mode is turned on, “Delayed” will be turned off automatically.
The following functions are not available in X-Y mode:
Auto measure, cursor measure, math operation, delayed sweep, vector display
type, HORIZONTAL POSITION, trigger control, screen grid, memory
depth, acquisition mode, Pass/Fail test and waveform recording.
Method 2: Use the shortcut measurement function
Please refer to “Phase A→B ” and “Phase A→B ” measurement functions of “Delay
and Phase ” on page 6-17.
