--Press the ByteLength softkey to set the length of data and the range is from
1 to 5;
--Press the CurrentBit softkey to select the desired data bit and the range is
from 0 to (ByteLength×8-1);
-- Press the Data softkey to set the data pattern of the current data bit to X, H
or L.
--Press the AllBits softkey to set the data pattern of all the data bits to the data
pattern specified in Data.
--press the Qualifier softkey and select “=”, “>” or “<”.
 A&D: trigger when the “Address” and “Data” conditions are met at the same
time. After this trigger condition is selected:
--press the AddrBits softkey to select “7 bit” or “10 bit”;
-- press the Address softkey to set the address value according to the setting in
AddrBits and the ranges are from 0 to 119 (8 addresses in 1111XXX format are
reserved) and from 0 to 1023 respectively;
-- Press the ByteLength softkey to set the length of data and the range is from
1 to 5;
-- Press the CurrentBit softkey to select the desired data bit and the range is
from 0 to (ByteLength× 8-1);
-- Press the Data softkey to set the data pattern of the current data bit to X, H
or L.
-- Press the AllBits softkey to set the data pattern of all the data bits to the data
pattern specified in Data.
-- press the Direction softkey to select “Read”, “Write” or “R/W”.
Trigger Mode:
Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto,
normal or single. The corresponding status light of the current trigger mode turns on.
Trigger Setting:
Press Set Up to set the trigger parameter (trigger holdoff) under this trigger type.
Trigger Level:
Use TRIGGER LEVEL to modify the trigger level of SCL or SDA channel. For
details, please refer to the description of “Trigger Level” on page 5-9.
