RIGOL 16 Specifications
16-4 DS6000 User’s Guide
Trigger
Trigger Level Range
Internal ±6 div from center screen
EXT ±0.8 V
Trigger Mode Auto, Normal, Single
Holdoff Range 100 ns to 10 s
High Frequency
Rejection
[2]
50 kHz
Low Frequency
Rejection
[2]
5 kHz
Edge Trigger
Edge Type Rising, Falling, Rising&Falling
Pulse Trigger
Pulse Condition Positive Pulse Width (greater than, lower than, within
specific interval)
Negative Pulse Width (greater than, lower than, within
specific interval)
Pulse Width Range 4 ns to 4 s
Slope Trigger
Slope Condition Positive Slope (greater than, lower than, within specific
interval)
Negative Slope (greater than, lower than, within specific
interval)
Time Setting 10 ns to 1 s
Video Trigger
Signal Standard Support standard NTSC, PAL and SECAM broadcasting
standards; support 480P, 576P, 720P, 1080P and 1080I
HDTV standards
Pattern Trigger
Pattern Setting H, L, X, Rising Edge, Falling Edge
RS232/UART Trigger
Trigger Condition Start, Error, Check Error, Data
Polarity Normal, Invert
Baud Rate 2400 bps, 4800 bps, 9600 bps, 19200 bps, 38400 bps,
57600 bps, 115200 bps, 230400 bps, 460800 bps,
921600 bps, 1 Mbps, User
