unchanged.
: adjust the upper and lower limits of the trigger level at the same time.
During the adjustment, the “UP Lvl” and the “Low Lvl” change accordingly but
the “Slew Rate” remains unchanged.
Trigger Mode:
Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto,
normal or single. The corresponding status light of the current trigger mode turns on.
Trigger Setting:
Press Set Up to set the trigger parameters (trigger coupling, trigger holdoff and
noise rejection) under this trigger type.
