16 Specifications RIGOL
DS6000 User’s Guide 16-5
Data Bits 5 bit, 6 bit, 7 bit, 8 bit
I2C Trigger
Trigger Condition Start, Restart, Stop, Missing ACK, Address, Data, A&D
Address Bits 7 bit, 8 bit, 10 bit
Address Range 0 to 127, 0 to 255, 0 to 1023
Byte Length 1 to 5
SPI Trigger
Trigger Condition CS, Timeout
Timeout Value 100 ns to 1 s
Data Bits 4 bit to 32 bit
Data H, L, X
Clock Edge Rising Edge, Falling Edge
CAN Trigger
Signal Type Rx, Tx, CAN_H, CAN_L, Differential
Trigger Condition SOF, EOF, Frame Type, Frame Error
Baud Rate 10 kbps, 20 kbps, 33.3 kbps, 50 kbps, 62.5 kbps, 83.3
kbps, 100 kbps, 125 kbps, 250 kbps, 500 kbps, 800 kbps,
1 Mbps, User
Sample Point 5% to 95%
Frame Type Data, Remote, Error, OverLoad
Error Frame Type
Bit Fill, Answer Error, Check Error, Format Error, Random
Error
FlaxRay Trigger
Baud Rate 2.5 Mb/s, 5 Mb/s, 10 Mb/s
Trigger Condition Frame, Symbol, Error, TSS
USB Trigger
Signal Speed Low Speed, Full Speed
Trigger condition SOP, EOP, RC, Suspend, ExitSuspend
