RIGOL

DS6000 User’s Guide

6-19

9. Overshoot: the ratio of the difference of the maximum value and top value of

the waveform to the amplitude value.

10. Preshoot: the ratio of the difference of the minimum value and base value of

the waveform to the amplitude value.
