Rigol DS6062-DEMO

RIGOL
DS6000 User’s Guide
12-21
Vertical Scale
10 dB Vrms/div
Vertical Scale
1.25 MHz
Sample Rate
50 MSa/s
Logic Operation
Expression
AND
Source A
CH1
Source B
CH1
Invert
OFF
Scale
1U
Advanced Operation
Expression
OFF
Expression
CH1+CH2
Vertical Scale
2 V
Protocol Decoding (MATH->BUS1/BUS2)
Decoding Type
Parallel
BUS Status
OFF
Ary
Hex
Offset
0
Threshold
0
Parallel
Clock Channel
None
Slope
Rising Edge
Data Bits
1
Channel Bits
0
Channel
CH1
RS232
TX
CH1
RX
CH2
Polarity
Negative
Endian
LSB
Baud
9600bps
Data Bits
8
Stop Bit
1
Even-Odd Check
None
Packet
OFF
