DS6000 User’s Guide

12-22

Packet End

NULL

SPI

SS Channel

OFF

SS Polarity

Positive

SCLK Channel

CH2

SCLK Slope

Rising Edge

MISO Channel

CH1

MISO Channel

Positive

MOSI Channel

CH1

MOSI Polarity

Positive

MOSI Data Bits

8

MOSI Endian

MSB

I2C

SCLK

CH1

SDA

CH2

Reference Waveform Setting (REF)

Channel Setting

REF1

Current Channel

REF1

Source

CH1
