5 To Trigger the Oscilloscope RIGOL
DS6000 User’s Guide 5-27
 FrameType: after this type is selected, press FrameType to select to trigger
on "Data", "Remote", "Error" or "OverLoad".
"Data" trigger:
--Press ID Setup and select "SpecificID" or "Random ID". When "SpecificID" is
selected, press ID Format and select "Standard" or "Expand"; press ID Data
and use
or the inner knob of the navigation knob to adjust the ID data
at the specified step (1) or rotate the outer knob of the navigation knob
to
quickly adjust the ID data within a relatively larger range. (The greater the
rotation amplitude of the outer knob, the faster the variations in the values.) The
range of the ID data is from 0 to 2047 (standard ID format) or 0 to 536870911
(expanded ID format).
--Press Byte Length and use to set the desired value. The range is from 1
to 8.
--Press CurrentBit to select the desired data bit and the range is from 0 to
(Byte Length×8-1).
--Press Data to set the data pattern of the current bit to X, H, or L.
--Press AllBits to set the data pattern of all the data bits to the data pattern
specified in Data.
"Remote" trigger:
--Press ID Setup and select "SpecificID" or "Random ID". When "SpecifiedID"
is selected, press ID Format and select "Standard" or "Expand"; press ID Data
and use
or the inner knob of the navigation knob to adjust the ID data
at the specified step (1) or rotate the outer knob of the navigation knob
to
quickly adjust the ID data within a relatively larger range. (The greater the
rotation amplitude of the outer knob, the faster the variations in the values.) The
range of the ID data is from 0 to 2047 (standard ID format) or 0 to 536870911
(expanded ID format).
 FrameError: after selecting this type, press Error Type to select to trigger on
the "Bit Fill", "AnswerError", "CheckError", "FormatError", or "RandomError".
Baud:
Press Baud to set the CAN baud to match the CAN bus signal. The available values
are 10 kb/s, 20 kb/s, 33.3 kb/s, 50 kb/s, 62.5 kb/s, 83.3 kb/s, 100 kb/s, 125 kb/s,
250 kb/s, 500 kb/s, 800 kb/s, 1 Mb/s (default), or User. After "User" is selected, press
User and use or the inner knob of the navigation knob to adjust the signal
rate with a small step value or rotate the outer knob of the navigation knob
to
quickly adjust the signal rate within a relatively larger range. (The greater the
