RIGOL 1 Quick Start
1-30 DS6000 User’s Guide
12. CH1 Label
 Display the on/off status of CH1. When it is turned on, the channel label is
highlighted.
 Display the vertical scale of CH1 (namely the voltage value per grid of the
CH1 waveform in the vertical direction). You can use VIRTICAL
SCALE
to modify this parameter.
 Different labels may be displayed according to the current channel setting.
For example,
is displayed when the "Channel Coupling" is AC; is
displayed when the "Bandwidth Limit" is enabled;
is displayed when
the "Input Impedance" is 50 Ω.
13. CH2 Label
 Display the on/off status of CH2. When it is turned on, the channel label is
highlighted.
 Display the vertical scale of CH2 (namely the voltage value per grid of the
CH2 waveform in the vertical direction). You can use VIRTICAL
SCALE
to modify this parameter.
 Different labels may be displayed according to the current channel setting.
For example,
is displayed when the "Channel Coupling" is AC; is
displayed when the "Bandwidth Limit" is enabled;
is displayed when
the "Input Impedance" is 50 Ω.
14. CH3 Label
 Display the on/off status of CH3. When it is turned on, the channel label is
highlighted.
 Display the vertical scale of CH3 (namely the voltage value per grid of the
CH3 waveform in the vertical direction). You can use VIRTICAL
SCALE
to modify this parameter.
 Different labels may be displayed according to the current channel setting.
For example,
is displayed when the "Channel Coupling" is AC; is
displayed when the "Bandwidth Limit" is enabled;
is displayed when
the "Input Impedance" is 50 Ω.
15. CH4 Label
 Display the on/off status of CH4. When it is turned on, the channel label is
highlighted.
 Display the vertical scale of CH4 (namely the voltage value per grid of the
