1 Quick Start RIGOL
DS6000 User’s Guide 1-31
CH4 waveform in the vertical direction). You can use VIRTICAL SCALE
to modify this parameter.
 Different labels may be displayed according to the current channel setting.
For example,
is displayed when the "Channel Coupling" is AC; is
displayed when the "Bandwidth Limit" is enabled;
is displayed when
the "Input Impedance" is 50 Ω.
16. Message Box
Display prompt messages.
17. Notification Area
Display the system time, sound icon, battery icon, USB storage device icon
and printer icon.
 System Time: displayed in "hh:mm (hour:minute)" format. When
printing or storing the waveform, the output file will contain this time
message. Press UTIL  System  System Time  System Time
to set through the following format:
yyyy-mm-dd hh-mm-ss (year-month-date hour-minute-second)
 Sound Icon: when sound is turned on, this area displays
. Press UTIL
 Sound to turn the sound on or off.
 Battery Icon: when the battery is used for power supply, this area
displays
.
 USB storage device: when the oscilloscope detects a USB storage
device, this area displays
.
 Normal Printer Icon: when the oscilloscope is correctly connected to a
normal printer, this area displays
.
 PictBridge Printer Icon: when the oscilloscope is correctly connected to
a PictBridge printer, this area displays
.
18. Operation MENU
Press any softkey to activate the corresponding menu. The following
symbols might be displayed in the menu:
Denote that
on the front panel can be used to select parameter
items. The backlight of
turns on when parameter selection is
valid.
