Rigol DSA1000 Series User Manual

RIGOL Front Panel Key Reference
2-46 User’s Guide for DSA1000 Series
2.3.4.7 Normalize
Eliminates the error from TG Level. Before using this function, connect the GEN
OUTPUT 50Ω output of TG with the RF INPUT 50Ω input of the analyzer.
1. Stor Ref
Saves the data of Trace 1 to Trace 3 as the reference value for normalization.
This operation should be done before you enable the normalization.
2. Normalize
Enables or disables the normalization. When enabled, the reference trace will be
stored automatically for after the current sweep completes if no reference trace is
stored before. During storing the reference trace, the interface displays
corresponding message. The trace data subtracts the corresponding value of
reference trace after every sweep.
3. Reference level
Adjusts the vertical position of trace on the screen when normalization is On.
 Being different from the Reference level function upon the AMPT menu,
this parameter has no influence on the reference level of the analyzer.
 You can use the numeric keys, knob or direction keys to modify this
parameter. For more details, please refer to “Parameter Input”.
Table 2-28 Reference level under normalization
Parameter Explanation
Default 0 dB
Range -200 dB to 200 dB
Unit dB
Knob Step 1 dB
Direction Key Step 10 dB
4. Norm Ref Pos
Adjusts this parameter to set the vertical position of the normalization reference
level on the screen when normalization is On.
 The same as the function of Reference level above, when setting this
parameter to 0%, the position of Reference level above will be at the bottom
of screen grip, when setting to 100%, it will be at the top.
