RIGOL Front Panel Key Reference
2-16 User’s Guide for DSA1000 Series
2.1.3.8 Auto Range
Adjusts the amplitude parameters within the specified span range automatically in
order to display the whole signal optimally on the grid.
Figure 2-6 Before the Auto Range
Figure 2-7 After the Auto Range
Key Points:
 Unlike Auto Scale, this function can solve the problem of an overrange
measurement due to parameter settings and adjust the max mixing level based
