RIGOL Menu Map
7-2 User’s Guide for DSA1000 Series
7.1 AMPT
AMPT
Amplitude
Input Atten
10 dB
Auto Manual
Auto Scale
Ref Level
0.00 dBm
Scale/Div
10.00 dB
Scale Type
Log Lin
Units
dBm
1/2
Units
dBuV
dBm
dBmV
Volts
Watts
1/1
Select
Cable
Off
Antenna
Other
User
1/1
Amplitude
RF Preamp
On Off
Ref Offset
0.00 dB
Auto Range
Corrections
MaxMixL
-10.00 dBm
Input
50 O 75 O
2/2
Corrections
Edit
Select
Off
Correction
On Off
Freq Interp
Log Lin
Delete
Corr Table
On Off
Corr Table
All Sel
1/1
Edit
Amplitude
0.00 dB
Point
1
Frequency
0 Hz
Del Point
1/1
Note: The “RF Preamp” menu is available for DSA1030/DSA1030-TG only.
