Rigol DSA1000 Series User Manual

Front Panel Key Reference RIGOL
User’s Guide for DSA1000 Series
2-121
2.7.2 Next Window
Press continuously to select one of the two windows alternately. The selected
window is highlighted, see figure below.
Figure 2-35 Switch between windows
Key Points:
 Pressing
(described in the following section) will zoom in on the selected
window so that you can observe the trace or measurement data more clearly.
 If a window is zoomed in and the display has been in Multiwindow mode,
continuously pressing
will display the two windows alternately.
