RIGOL Front Panel Key Reference
2-50 User’s Guide for DSA1000 Series
Select the TOI measurement and press Meas Setup to set corresponding
parameters.
9. Pass/Fail
Compares the measured curve with the pre-edited, if the related rules are met,
the result will be “Pass”, or else is “Fail”.
Select the Pass/Fail measurement and press Meas Setup to set corresponding
parameters.
2.4.1.2 Restart
Re-executes the active or suspended measurement.
2.4.1.3 Pause
Suspends the measurement after current measurement. However, the sweep is
continuous when pressed, an icon
is shown on the results window, and the
measurement data stops updating.
2.4.1.4 Resume
Restarts the suspended measurement. An icon is shown at the result window, and
the measurement data begins updating again.
2.4.1.5 Meas Mode
Sets the measurement mode to Single or Continue. In single mode, the analyzer stops
after a specified number of measurements. After this, every time you press Single,
measurements will be executed a specified number of times and measurement data
will be updated. In Continue mode, the analyzer measures continuously.
