Rigol DSA1000 Series User Manual

RIGOL Front Panel Key Reference
2-70 User’s Guide for DSA1000 Series
Table 2-50 Average number for Harmo Dist measurement
Parameter Explanation
Default 10
Range 1 to 1000
Unit
N/A
Knob Step 1
Direction Key Step 1
2. Avg Mode
Sets the Average operation to Exp or Repeat, the default is Exp.
 In Exp mode, the result is from the exponent average calculation of the
current N (specified by Avg Num) measurements.
 In Repeat mode, the result is the arithmetic average of the current N
(specified by Avg Num) measurements.
3. NO.of Harmo
Sets the number of harmonics to be measured, which is used for calculating the
total harmonics.
You can use the numeric keys, knob or direction keys to modify this parameter.
For more details, please refer to “Parameter Input”.
Table 2-51 Number of harmonics for Harmo Dist measurement
Parameter Explanation
Default 10
Range
2 to 10
Unit N/A
Knob Step 1
Direction Key Step 1
4. Harmonic ST
Sets the sweep time during the harmonic measurement, which is the sweep time
of the analyzer.
You can use the numeric keys, knob or direction keys to modify this parameter.
For more details, please refer to “Parameter Input”.

Rigol DSA1000 Series Specifications

General

Brand	Rigol
Model	DSA1000 Series
Category	Measuring Instruments
Language	English
