RIGOL Front Panel Key Reference
2-114 User’s Guide for DSA1000 Series
2.6.4.12 Delete
Deletes the selected file.
2.6.4.13 Disc Mgr
1. Format (D:)
Formats the local disk.
2. Disk Info
View the disk information such as disk name, disk type (local or USB storage
device), file system, the used space and the total space.
2.6.4.14 Name Prefix
1. Prefix Switch
Enables or disables the edited prefix name. The input box will automatically load
the prefix name after you press Save when Prefix Switch is set to On.
2. Edit
Edits the required prefix name by using the virtual keyboard. Up to 15 characters
can be entered.
2.6.4.15 System Update
Updates the analyzer software after selecting the update file in the connected USB
storage device.
