10 | Linear installation guide 13563-B 02-19
The Linear has a fan that distributes warm air from the top of the appliance out into
the room. As warm air is dispersed outwards and not directly upwards, installation
of a TV may be an option.
The diagram shows recommended clearances when installing a TV directly above the Linear, or
into a recess. All dimensions are in millimetres.
Always check with the TV manufacturer
It is up to the owner to check the TV installation with the TV manufacturer—some have warranty
conditions that state a TV is not to be installed above a replace.
Rinnai does not accept any responsibility for damage to a TV resulting from the use of this
information.
400 mm 400 mm
TV installation
