4 | Linear installation guide 13563-B 02-19
Before you start
Unpack the appliance and components and check for damage. DO NOT install any damaged
items. Check all components have been supplied, refer table below, and that you have the correct
gas type.
Read these instructions to get an overview of the steps required before starting the installation.
Failure to follow these instructions could cause a malfunction of the appliance. This could result in
serious injury and/or property damage.
Linear boxed dimensions
H
W
D
Linear 800 Linear 1000 Linear 1500
Height
Width
Depth
Weight
1156 mm
1350 mm
530 mm
120 kg
931 mm
1550 mm
530 mm
125 kg
931 mm
2050 mm
530 mm
140 kg
What comes with what
With the Linear engine comes the:
- Glass frame
- Remote control (batteries included)
- Flue lock bracket and truss screws (x2)
- Operation and Installation guides
- Burn media installation guide
- Colour burn media placement sheet (attached to the glass frame)
- Commissioning sheet (attached in a plastic pouch inside the unit)
- Reducing are
- Linear 800 FlameTech or standard log set (inside the engine)
The burn media for the Linear 1000 and 1500 models will come packaged separately in one large
box.
Flue components and accessory items are ordered separately.
