33
Reading the Display
Memory field
Shows the selected memory store mode (Manu, Auto 1, or Auto 2).
Card insertion indicator
This indicator appears when a memory card is inserted.
Level range indicator
Shows the upper and lower limit of the bar graph. Make the setting that is
appropriate for the sound level.
Bar graph
Shows the sound level. The indication is updated every 100 milliseconds.
Over-range indicator (shown as
O v
for sound level)
Shown for at least 1 second when sound level overload has occurred.
Over-range indicator (shown as
O v
for processed value)
Shown when any of the processed values contains an over-range level. Lights
up when over-range occurs during processing and stays lit until the next
processing measurement starts.
Level reading
Normally, this shows the sound level (updated every second).
Time weighting indicator
Shows the selected time weighting setting.
Filter frequency indicator
Shown when the 1/1 octave, 1/3 octave universal filter program has been
installed.
