Compact Flash Card
Direct Card Write Function
When the SAVE DISPLAY item on the PCMCIA card menu is set to ON,
pressing the STORE key in the measurement mode causes all data including
data outside of the current display range to be stored directly on the card (direct
card write function).
For example, when the unit is in analyzer mode and the ZOOM ratio is set to
2×, the total amount of data will be 202 lines, but only 102 lines are displayed.
With regular mass memory store, only the data for the displayed 102 lines will
be written to the card. With the direct card write function, the data for all 202
lines are written to the card. In this case, an "F" is shown in front of the address
indication.
Address indication example: F 123
Note
When the direct card write function is ON, a data
writing operation corresponding to transient store is
not possible.
When the direct card write function is ON, the mass
memory recall operation is not possible.
When a card related error has occurred, the card symbol on the display flashes.
If no card is inserted, the card symbol flashes and the address indication shows
"F∗∗∗∗".
