Cloud server.
1.4 Status Indications
LED Indicators
The LED indicators provide typical system indications, as discussed
below. Some indicators have additional functions, which are explained
later on.
Power LED (Green)
The Power LED indicates system operation.
Condition
Description
On
Power OK
Rapid flash
Indicates AC fault
Slow flash
Indicates low battery fault
Set/Alarm LED (Red)
Condition
Description
On
System Set
Rapid flash
Alarm
Slow flash
System in Exit delay
Part set LED (Red)
Condition
Description
On
System armed at PART SET
Off
System Unset
Ready LED (Green)
Condition
Description
On
System Ready
Off
Open zones
Slow Flash
System is ready to be set while a specially
designated entry/exit door remains open
Fault LED (Amber)
Condition
Description
Rapid Flash
Fault
Off
No fault
Note: When all LEDs flash one after another in sequence the system is in Learning mode.
