Operation
1
Quick Operation
High Security Mode
Changing Keypad
Language
Press and hold simultaneously for 2 seconds. Select the
language and press to confirm.
All operations are available while keypad is turned on (Not in Sleep Mode)
Ask your engineer whether outputs control is applicable or not and which output is
assigned to which key
Ask your engineer for the macro defined for each key
Ask your engineer for the keys definition
LEDs Indication
Key
Function
(Blue)
Communication with the panel
(Red)
 On: Fully or partially set
 Slow flash: Exit delay
 Rapid flash: Alarm
(Yellow)
Fault in the system during unset mode
