Rittal 7844440 - Rear Door Installation Kit

Page 41 DCN 4727 REV 6 Doc No. C29115
Rear Door Installation Kit
Caution
WORKING WITH RACK
• This rack is easily tipped, ensure rack is secured.
• Instructed or Skilled persons to handle rack only.
• People handling the rack must wear PPE in accordance with local risk assessments and local
regulations.
Failure to follow these instructions can result in injury or equipment damage.
WARNING
MANUAL HANDLING & TRIP HAZARD
• Due to size and weight of the rack doors and cladding, never attempt to remove or install them by
yourself.
• When storing doors, lay the doors flat so they do not fall over, causing accidental injury.
Failure to follow these instructions can result in injury or equipment damage.
Door Accessory Kit
Part No
Description
7844151
42U Rear Door Kit
7844153
48U Rear Door Kit
Contents List
Item
Description
Qty.
1
Hinge
8
2
Rear Lock
Bracket (RLB)
2
3
Screw (RLB)
M5x12mm CSK
2
4
Screw
M6x10mm CSK
8
5
Master Rear
Door Assembly
1
6
Slave Rear
Door Assembly
1
7
Serrated
Contact Washer
2
8
Plain Washer
2
9
Grounding Wire
2
10
Screw 5.5x10
2
11
Hinge Clip
4
