Page 43 DCN 4727 REV 6 Doc No. C29115
Rear Door fitting
1. Install back door hinges with 1 off M6x10mm screw for each hinge. Torque 5 – 6 Nm
2. Each door requires 4 hinges in the correct locations as shown.
First hole from bottom
First hole from top
First hole from bottom
First hole from top
