Page 47 DCN 4727 REV 6 Doc No. C29115
Lock Replacement (Unique or Standard)
WORKING WITH RACK
• This rack is easily tipped, ensure rack is secured.
• Instructed or Skilled persons to handle rack only.
• People handling the rack must wear PPE in accordance with local risk assessments and local
regulations.
Failure to follow these instructions can result in injury or equipment damage.
Replacement unique locks available from distributors.
Unique Lock Insert options
Burg Lock Insert PN: No1-67:PF MS Z70001 to No1-67:PF MS Z70201
Example:
No1-67:PF MS Z70001 (First number in series… 001)
No1-67:PF MS Z70002 (Second number in series… 002)
No1-67:PF MS Z70… (Incremental numbers…003 through 200 in series)
No1-67:PF MS Z70201 (Last number in series… 201)
To change follow as below.
1. Open door and ensure handle is fully open to gain access to handle screws (x2)
2. Remove screws (2x M5x8 T25 csk) and retain.
This removes the handle from the door.
To Next Page
