Rittal 7844440 - Hinge and lock catch positions

Page 38 DCN 4727 REV 6 Doc No. C29115
Hinge and lock catch positions
Secure Hinges and lock catches Torque 5 – 6 Nm
Hinge Positions Lock Catch Positions
Lock Catch Screw Fitting
Positions
(Top to Bottom)
1
st
B
2
nd
B
3
rd
B
4
th
B
A
B
D
C
First hole from bottom
First hole from top
First hole from bottom
First hole from top
